GeoSIG GXR-GPS
Key Features
- 1 microsecond time accuracy
- <3 m position accuracy DGPS 15 m position accuracy Non-DGPS
- <2 seconds re-acquisition 15 seconds warm acquisition 45 seconds cold acquisition
- Programmable update rate from 1 second to 15 minutes
- Built in antenna
- Rugged, water resistant housing
The GXR-GPS, now a legacy product, was a state of the art GPS receiver module which employed GARMIN GPS-18: a complete GPS receiver and embedded antenna designed for a broad spectrum of system applications.
The GPS-18 tracked up to twelve satellites at a time while providing one-second navigation updates and low power consumption. Its far-reaching capability met the sensitivity requirements of seismic applications.
The GPS-18 design utilised the latest technology and highlevel circuit integration to achieve superior performance while minimising space and power requirements.
The GXR-GPS was housed in a water-resistant case and was designed to withstand rugged operating conditions. The host system could communicate with the GXR-GPS via a dedicated, compatible, bi-directional communication channel. Internal memory backup allowed the GXR-GPS to retain critical data such as satellite orbital parameters, last position, date, and time.
The GPS-18 tracked up to twelve satellites at a time while providing one-second navigation updates and low power consumption. Its far-reaching capability met the sensitivity requirements of seismic applications.
The GPS-18 design utilised the latest technology and highlevel circuit integration to achieve superior performance while minimising space and power requirements.
The GXR-GPS was housed in a water-resistant case and was designed to withstand rugged operating conditions. The host system could communicate with the GXR-GPS via a dedicated, compatible, bi-directional communication channel. Internal memory backup allowed the GXR-GPS to retain critical data such as satellite orbital parameters, last position, date, and time.
