GeoSIG GXX-3GUX Series 3G Modem
Key Features
- HSPA & Tri-Band GSM, upto 3.6 Mbps download
- USB interface
- High speed wireless network support
Now a legacy product, the GXX-3GU series were 3G modems which provided a secure wireless connection using the 3G network infrastructure for high speed data communications. The GXX-3GU was a Multi-Band module solution with HSDPA as well as GSM/GPRS/EDGE with up to 3.6 Mbps for downlink data transfer. The 3G modem could be delivered as an external module, connected to and powered directly from GMSplus series recorder. The unit was delivered with all necessary accessories, and peripheral units such as the cabling, connectors, antenna, etc as well as firmware & software, thus was ready to use out of the box together with the associated GeoSIG solution.
-
functionality
- bands:
- HSPA & Tri-Band GSM 900/2100 MHz HSPA 850/900/1800 MHz GSM/GPRS/EDGE
- output power:
- HSPA Class 3 (0.25W) GSM850/GSM900 Class 4 (2W) GSM1800 Class 1 (1W)
- sim card:
- Supports 1.8 and 3 V SIM cards Mini SIM (25 mm x 15 mm)
-
management - configuration
- Through GMSplus
-
Data Transfer (maximum values)
- HSDPA:
- 3.6 Mbps DL/UL
- edge/GPRS:
- Multi-Slot Class 12
-
power (powered directly from the GMSplus) - consumption:
- 56 mA standby 140 mA Peak Tx
-
dimensions
- GXX-3GUE:
- 80 mm x 160 mm x 60 mm
-
weight
- GXX-3GUE:
- approx. 300 g incl. cables
-
Environmental Protection
- GXX-3GUE:
- IP65, optional IP66 / IP67
-
TEmperature
- operation:
- -30 to +80 °C
- storage:
- -40 to +85 °C
-
**Specifications subject to change without notice
