GeoSIG GMS-GPS
Key Features
- Concurrent reception of up to 3 GNSS (GPS, Galileo, GLONASS, BeiDou)
- Supports all satellite augmentation systems and Assisted GNSS (A-GNSS)
- 30 nanosecond time accuracy (RMS)
- < 2.5 m position accuracy GPS
- < 1 second re-acquisition
5 seconds warm acquisition
45 seconds cold acquisition - RS232 or optionally RS485 communication
- Built-in antenna or external antenna
- Rugged, water resistant housing
The GMS-GPS is a state of the art GPS receiver module which employs U-BLOX NEO-M8N that is a complete GPS receiver and embedded antenna designed for a broad spectrum of system application.
The NEO-M8 module is concurrent GNSS receiver, which can receive and track multiple GNSS systems: GPS, Galileo, GLONASS and BeiDou. Its far-reaching capability meets the sensitivity requirements of seismic applications and low power consumption.
The NEO-M8N design utilises the latest technology and high level circuit integration to achieve superior performance while minimising space and power requirements.
The GMS-GPS is housed in a water-resistant case and is designed to withstand rugged operating conditions. The host system may communicate with the GMS-GPS via a dedicated, compatible, bi-directional communication channel. Internal memory backup allows the GMS-GPS to retain critical data such as satellite orbital parameters, last position, date, and time.
The NEO-M8 module is concurrent GNSS receiver, which can receive and track multiple GNSS systems: GPS, Galileo, GLONASS and BeiDou. Its far-reaching capability meets the sensitivity requirements of seismic applications and low power consumption.
The NEO-M8N design utilises the latest technology and high level circuit integration to achieve superior performance while minimising space and power requirements.
The GMS-GPS is housed in a water-resistant case and is designed to withstand rugged operating conditions. The host system may communicate with the GMS-GPS via a dedicated, compatible, bi-directional communication channel. Internal memory backup allows the GMS-GPS to retain critical data such as satellite orbital parameters, last position, date, and time.
-
General Characteristics
- Reciever:
- Differential ready 12 parallel channel receiver tracks and uses up to twelve satellites to compute and update
- Supported GNSS:
- GPS, Galileo, GLONASS and BeiDou
- Cable:
- 20M standard, up to 70M possible with RS232. Or up to 300 m with RS485 option.
- Antenna:
- Built in (or optionally external)
-
Cable Specifications - Conductor:
- 5 X 0.25 for RS232, or 4 x 2 x 0.25 for RS485
- Conductor Marking:
- DIN 47100
- Outer Jacket
- PVC UL Style, Grey
- Temperature range:
- -30°C to 80°C
- Minimum Bending radius:
- 10 X cable
- Diameter:
- 5.1 mm
-
Acquisition Times - Update Rate:
- 1 sec, continuous
- Acquisition*:
- < 1 sec; re-acquisition
2 sec; warm (all data known)
45 sec; cold (position, time and almanac known) - Interfaces
- RS232 or RS485 compatible
- Protocol
- NMEA 0183, version 4.0
-
Accuracy - Time:
- 30 nanosecond RMS, (60ns within 99% pulses)
-
position
- Differential GPS (DGPS):
- < 3 m
- Non-differential GPS:
- < 15 m,
Subject to accuracy degradation to 100 m 2DRMS under the Selective Availability Program. -
PPower - Input Voltage:
- 4.5 - 15 VDC, typically 65 mA @ 12 VDC. All signals have overvoltage and overcurrent protections.
-
Environment/housing
- Size:
- 82 mm x 162 mm x 55 mm
- Weight:
- 200 g, not including cable
- Operating Temperature:
- -30°C to +80°C (internal temperature)
- Storage Temperature:
- -40°C to +80°C
- Index Of Protection:
- IP 65
-
**Specifications subject to change without notice
