GeoSIG ETH-LLAN Ethernet Module
Key Features
- 5.7-15 Mbps over single twisted pair copper cable
- SHDSL and SHDSL.bis, 3 km or more
- Channel bonding for up to 2 pairs
- Point-to-Point, Point-to-Multipoint, Add/Drop, Ring applications
- Integrated 2 port Ethernet switch
- Robust metal housing
The ETH-LLAN utilizes the SHDSL technology which allows data transmission at speeds up to 15 Mbps over a single twisted pair of copper wire. In addition, ETH-LLAN supports DSL channel bonding for up to 2 copper pairs in order to achieve speeds to 30 Mbps.
An integrated 2 port 10/100BaseT Ethernet managed switch with enables the use of your distributed networked devices over simple, cost efficient, and site friendly copper cabling.
Combination of this quality with comprehensive functions providing maximum flexibility makes the ETH-LLAN the most efficient long distance cable link solution between any GeoSIG instrument or computer.
ETH-LLAN design is based on high grade industrial components and it is manufactured according to highest quality standards.
An integrated 2 port 10/100BaseT Ethernet managed switch with enables the use of your distributed networked devices over simple, cost efficient, and site friendly copper cabling.
Combination of this quality with comprehensive functions providing maximum flexibility makes the ETH-LLAN the most efficient long distance cable link solution between any GeoSIG instrument or computer.
ETH-LLAN design is based on high grade industrial components and it is manufactured according to highest quality standards.
-
SHDSL
- Standard:
- ITU-T G.991.2, G and G.bis
- Line Code:
- TC-PAM16/32
Optional 4/8/64/128 - Transmit Power:
- 13.5 (An.A)/14.5 (An.B) dBm @ 135Ω
- Number of pairs:
- 2, supporting channel bonding
- Data Range:
- upto 5.7 Mbps
Optional upto 15 Mbps - Over voltage protection
- ITU-T Rec. K.20/K.21
- Matching Cable:
- AWG 16-26, 0.14–1.5 mm2 twisted copper pair
-
Ethernet
- Standards
- IEEE-802.3, VLAN/QoS IEEE-802.1q/p
- Number of interfaces
- 2
- data range
- 10/100BaseT, Full/Half Duplex
- protocols
- Data, Telnet, SNMP, WEB with MDI/MDI-X Auto Crossover, Auto Negotiation
- Connector
- RJ45 Female, 8 pin
-
terminal
- Standards:
- USB V2.0 full and low speed
- Data range:
- 12Mbit/s
- protocol:
- Master/Slave
- Connector:
- USB Type Mini-B female connector
-
power
- voltage:
- 9-18 or 18-72 VDC or 90-260 VAC
- matching cable:
- AWG 12-24, Area 0.2–2.5 mm2
- Consumption:
- Typically 4 W
-
environment/housing
- size:
- 143 x 87 x 37 mm
optional 153 x 87 x 37 with DIN rail mount
optional external housing dimensions
definded per project - weight:
- <500 g
- operating temperature:
- -25°C to +80°C
- Storage temperature:
- -25°C to +80°C
- index of protection:
- IP 30
optional in IP65 external housing -
**Specifications subject to change without notice
