GeoSIG TEL-WLx Wireless LAN Communication System
Key Features
- 2.4 GHz operation
- Protected WLAN Network
- Up to 30 kilometre operating range
- Point to point / Point to multi point
- Weather resistant enclosure
- Easy connection and wiring
GeoSIG's TEL-WLx Wireless LAN Communications System offers versatility and ease of use in a variety of locations and applications.
TEL-WLx allows combining a number of field stations to one single network, which feature easy data acquisition and maintenance. The authorised user has access to the data from every node inside the network. Additionally it is possible to change the settings of every field station and the equipment attached to it from a remote location. At the same time the network is fully protected from unauthorised access by WEP encryption.
In point to point mode wireless connections up to 30 km are possible. If the distance is shorter, point to multi point configurations are possible.
GeoSIG is able to assist its customers in finding the right equipment for their project as well as in the evaluation of potential telemetry links. Global terrain data allows GeoSIG to calculate line of sight profiles anywhere around the world.
TEL-WLx allows combining a number of field stations to one single network, which feature easy data acquisition and maintenance. The authorised user has access to the data from every node inside the network. Additionally it is possible to change the settings of every field station and the equipment attached to it from a remote location. At the same time the network is fully protected from unauthorised access by WEP encryption.
In point to point mode wireless connections up to 30 km are possible. If the distance is shorter, point to multi point configurations are possible.
GeoSIG is able to assist its customers in finding the right equipment for their project as well as in the evaluation of potential telemetry links. Global terrain data allows GeoSIG to calculate line of sight profiles anywhere around the world.
-
radio characterisitcs
- frequency range:
- 2300 to 2500 MHz
- RF output power:
- 20 dBm (100mW)
- Range, Line-of-sight*:
- 30 km
- RX sensitivity:
- 802.11g: -87 dBm @ 6Mbps 802.11b: -92dBm @ 1MBps
- method:
- 802.11b/g
- RF connector:
- Type N female
- impedance:
- 50 Ohm
- antenna type:
- 610mm dish
- antenna gain:
- 21dBi
- antenna freq. range:
- 2400-2485 MHz
- antenna VSWR:
- =1.7:1
-
system connections
- data connection:
- RJ45
- power connection:
- PoE via RJ45
-
power requirements
- supply voltage:
- 18-28 VDC (PoE)
- power consumption:
- Typical ~3W. Maximum 12W.
-
environment
- operating temperature:
- -30 °C to +60 °C
- operating humidity:
- 0-90% relative (outdoor parts) 0-70% relative (indoor parts)
-
dimentions
- mast diameter required:
- 35-50 mm
- antenna diameter:
- 610 mm
- antenna depth:
- 150 mm excl mounting bracket 250 mm incl mounting bracket
- transciever dimentions:
- 200 x 150 x 55 mm 260 x 260 x 120 mm (Weather shield)
- ethernet OVP dimentions:
- 75 x 36 x 19 mm
- poe injecter dimentions:
- 85 x 76 x 36 mm
-
**Specifications subject to change without notice
